Schwenksitz in einem Paravan Chrysler Voyager
PARAVAN swivel seat
Comfortable entry

The PARAVAN swivel seat

The patented PARAVAN swivel seat system for the front passenger’s side of the vehicle

Taking a seat on the front passenger’s side of your car safely and conveniently, sitting comfortably throughout the journey and easily exiting afterwards without any discomfort – we can simultaneously fulfil all these requirements with our patented seat system: The PARAVAN swivel seat.

Schwenksitz eingeschwungen im Auto
Schwenksitz als Umstieghilfe auf der Beifahrerseite
Einstiegshilfe Auto: Schwenksitz ausgeschwungen
Highlights at a glance
Schwenksitz als Einstiegshilfe ins Fahrzeug
01

Entry aid for the front passenger’s side

A complete vehicle seat solution for the front passenger’s side – with a clever swivel mechanism.

Schwenksitz mit Sitzlängenverstellung
02

Comes to meet you

The electric seat length adjustment feature enables the PARAVAN swivel seat to move 20 cm closer to you after it’s been turned, which significantly facilitates entry into the vehicle.

Modularer Schwenksitz einschwingend
03

The system can also be used with an original seat

The PARAVAN swivel seat base’s modular design is so advanced as to allow original vehicle seats to be used as swivel seats – in many different types of vehicles.

Your benefits
Enjoy the entry
  • Excellent production and product quality – “Made in Germany”
  • Successfully crash-tested in line with the requirements of the ECE-R 17 guideline and 74/408/EEC
  • Patented swivel system
  • Optional stand-up aid available (electrically raised seat surface)
  • Plenty of legroom during swivel movements
  • Maximum load-bearing capacity of 160 kg; with stand-up aid: 120 kg
  • Large swivel range (up to 120 degrees; depends on the vehicle type in question)
  • Fast, powerful and low-noise motors
  • Optional electric length adjustment (one or two units)
  • Can be operated manually or electrically
  • Cable remote control possible (Paravan system)
  • Radio remote control possible (Paravan system)
Schwenksitz mit umsitzenden Rollstuhlfahrer
Outstanding seat quality and comfort
  • Integrated emergency release function
  • Integrated (extendible) vehicle-specific footrest available as an option
  • Integrated fixation point for the standard seat belt, individually adjustable
  • Optional individually adapted seat (Type K410)
  • Original vehicle seats can be used in some cases
  • Can be adapted for use with all types of vehicles (cars, lorries, industrial vehicles, camper vans)
  • Developed entirely in-house
  • Produced entirely in-house
  • Fast service thanks to a comprehensive network of partners
  • 24-hour delivery of spare parts
  • Worldwide dealership network
Leder Schwenksitz ausgeschwungen
Looking for a contact person?
PARAVAN swivel seat models:
Feature: Mechanical swivel seat Electric swivel seat Electric swivel seat with stand-up function
Operation: Mechanical with lever Electric radio or cable remote control Electric radio or cable remote control
Max. angle of rotation:   120° 120° 120°
Crash test passed: Yes Yes Yes
Max. load-bearing capacity: 160 kg 160 kg 160 kg
Suitable for use in all common vehicle types: Yes Yes Yes
Emergency release function: -- Yes Yes
Electric length adjustment: 240 mm (horizontal) forwards/backwards in the vehicle 240 mm (horizontal) forwards/backwards in the vehicle 240 mm (horizontal) forwards/backwards in the vehicle
Double electric length adjustment: 240 mm (vertical) forwards/backwards in the rotated position 240 mm (vertical) forwards/backwards in the rotated position 240 mm (vertical) forwards/backwards in the rotated position

The PARAVAN swivel seat – the perfect entry aid for the front passenger’s side of the vehicle

Because a good journey calls for a good seat!

We have teamed up with highly-qualified physiotherapists and ergotherapists to develop a special seat for our swivel seat base. This seat not only offers maximum vehicle comfort, but also ensures an orthopaedically correct sitting position. We can fulfil every wish, even where the seat cover is concerned. You can choose between a range of standard colours and materials or opt for elegant leather upholstery. Our customer advisers will be delighted to help you.

Schwenksitz als Einstiegshilfe für Menschen mit Behinderung
Your perfect entry aid is just a click away
Seat collection product sheet
The PARAVAN swivel seat

Product details, benefits and technical data




Download PDF
